0W
Input voltages from 50kV to 450kV
Measurement accuracy as high as ≤0.1%
High stability of 0.2%
Temperature coefficient 15ppm/°C
Voltage coefficient of 0.12ppm/V
Roller mounted design for easy positioning
BNC connector

High precision, low noise solutions up to 500kVDC with output power to 600kW
Exceptional reliability, accuracy and performance in a small size are essential for high voltage applications. Design engineers working in semiconductor manufacturing equipment, industrial technology and healthcare also want functionality and ease of integration in multiple form factors.
You can depend on our power supplies and design & technical support to solve your high voltage power challenges.

Our design expertise provides accuracy, quality and reliability
We partner with you so that when your resources and deadlines are tight, our customer-focused direct sales and global design-in & support will help you achieve your goals.
We have standard, modified and custom high voltage power solutions to address your specific design needs, whatever they are. Our extensive design validation and testing processes ensure your end products are efficient, safe and last a lifetime.

Facing tight project schedules, complex integration, regulatory hurdles and demanding safety standards?
Our expert engineers work closely with your team to develop scalable, application-specific power solutions. With extensive experience in intricate design and a global manufacturing reach, we deliver cost-effective, custom solutions built to the highest standards, ensuring seamless alignment with your design parameters.
We resolve your power supply challenges, allowing you to focus on business priorities.
Designed for the healthcare, semiconductor manufacturing equipment and industrial technology sectors.
>> Scroll through the application options below to discover how we can support your specific needs.
Low ripple and noise, load, and line regulation down to 1 PPM
Output voltage range of 100VDC to 500kVDC
Power range of 2mW to 600kW
0-100% programmable voltage and current
Negative, positive, reversible polarity
Analog, RS232, LAN, EtherCAT and Ethernet controls
Input and output protection with built-in industry safety approvals
Available in multiple form factors
Reliable, safe power supplies are needed in high voltage applications to guarantee trouble-free operation.
In high voltage power supplies the output stage is capacitive by nature, which results in stored energy. During an arc discharge, the stored energy inside the power supply is quickly dispersed through an internal limiting resistance and carries high peak currents through the load.
The high energy pulse magnitude (EMT pulse) that occurs during an arc can damage the high voltage power supply and the load, as well as potentially disrupt sensitive control and microcontroller circuitry.
Our high voltage power supplies feature arc current limiting and arc sensing circuitry to protect the load from arcing damage.
If you don’t address isolation requirements properly or make poor insulation choices, then your power supply could become destabilized. You should also ensure that moisture is not being absorbed into the device and guard against leakage currents.
Our industry-leading design and manufacturing controls ensure longevity and consistent performance in your critical applications.
Our diverse range includes thousands of high voltage products, easily searchable by power, voltage, format and application.
Found:112 series1733 models
| Model number | Output voltage | Current | Power | Actions |
|---|---|---|---|---|
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 10V | - | - | ||
| 100V | 15mA | 1.5W | ||
| 100V | 10mA | 1W | ||
| 100V | 10mA | 1W | ||
| 100V | 10mA | 1W | ||
| 100V | 10mA | 1W | ||
| 100V | 10mA | 1W | ||
| 100V | 10mA | 1.5W | ||
| 100V | 10mA | 1W | ||
| 100V | 30mA | 3W | ||
| 100V | 15mA | 1.5W | ||
| 100V | 5mA | 0.5W |

0W
Input voltages from 50kV to 450kV
Measurement accuracy as high as ≤0.1%
High stability of 0.2%
Temperature coefficient 15ppm/°C
Voltage coefficient of 0.12ppm/V
Roller mounted design for easy positioning
BNC connector

0.44W - 1.5W
Output voltages up to 6kVDC
Reversible positive or negative polarity
Dual output versions
Isolated output voltage proportional to input voltage
Input voltage 0.7VDC to 12VDC
Low turn on voltage: <0.7VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
General purpose, cost effective
MTBF>2.29Mhrs
3 year warranty

0.5W
Output voltages up to 10kVDC
Reversible, positive or negative polarity
Dual output versions
Isolated output voltage proportional to input voltage
Input voltage +5V, +12V & +24VDC
Low turn on voltage: <0.7VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
MTBF>3Mhrs
3 year warranty

1W
Output voltages up to 6kVDC
Isolated output voltage proportional to input voltage
Positive or negative polarity
Ultra-miniature, low profile, SMT
Low turn on voltage: <0.7VDC
Input voltage 5V, 12V & 24V
Input to output isolation 500VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
MTBF>1.8Mhrs
Operating temperature -25°C to +75°C
3 year warranty

1W
Output voltages up to 6kVDC
Isolated output voltage proportional to input voltage
Positive or negative, reversible polarity
Low turn on voltage: <0.7VDC
Low power consumption
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
MTBF>2.31Mhrs
3 year warranty

Input: +24VDC
Output: up to ±6kV reversible (bias)
Other output voltages available on request
Switching speeds of 25ms; optional 5ms
Output voltage and current regulated
Voltage & current monitor outputs
Short circuit, arc, & overload protection
Low ripple, high stability
Designed to meet UL61010
Operating temperature: +10°C to +60°C
3 year warranty

1.4W
0 to ±1.25kV bipolar output
4 quadrant operation with active load
Constant voltage control and current limitation with automatic transfer and control mode dispay with LED’s
Single phase AC input
Continuous operation at full rated power
Digital, LAN and USB interface option
Analog programming/interface option
Manual voltage control via 10 turn potentiometer
Digital display for current and voltage
Set-point display via a button
Set-point adjustment possible with disabled output
Push-button switch for output voltage
CE marked, EN61010-1 safety compliant
Short circuit & arc protection
2 year warranty

Input: +24VDC
Output 1: up to ±12kV reversible (bias)
Output 2: up to -5kV (multiplier)
Other output voltages available on request
Switching speeds of 25ms; optional 5ms
Output voltage & current regulated
Voltage and current monitor outputs
Short circuit, arc, & overload protection
Low ripple, high stability
Designed to meet UL61010
Operating temperature: +10°C to +60°C
3 year warranty

1W
Output voltage 0 to 10kVDC
Positive or negative
0 to 100% programmable
Precision regulated
Voltage and current monitors
Calibration trim-pot
Input voltage 12VDC
Low noise, quasi-sinewave resonant oscillator
Steel case with isolated case ground
MTBF>2.6Mhrs
3 year warrranty

1W
Output voltages up to 2kVDC
Positive or negative
0 to 100% programmable
Precision regulated
Calibration trim-pot
Low noise, quasi-sinewave resonant oscillator
Input voltage 5 & 12VDC
Shielded case with isolated case ground
MTBF>2.1Mhrs
Wide operating temperature -55°C to +70°C (case)
3 year warranty

1W
Output voltages up to 2kVDC
Positive or negative
0 to 100% programmable
Precision regulated
Very low ripple
Calibration trim-pot
Low noise, quasi-sinewave resonant oscillator
Input voltage 5 & 12VDC
Shielded case with isolated case ground
MTBF>2.1Mhrs
Wide operating temperature -55°C to +70°C (case)
3 year warranty

1W
Output voltages up to 8kVDC
Precision voltage regulated output
Positive or negative output versions
0 to 100% programmable
Calibration trim-pot
Ultra-low noise, magnetic free design
Low ripple - down to 0.002%
<50ppm/°C temperature coefficient
Input voltage (nominal) 12 to 15VDC
MTBF>2.6Mhrs
Shielded case with isolated ground
-10°C to +60°C case operating temperature
3 year warranty

1W
Output voltages up to 6kVDC
Positive or negative outputs
Isolated output voltage proportional to input voltage
Input voltage 5V, 12V & 24VDC
Low turn on voltage: <0.7VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
Ultra-miniature, low profile
MTBF>1.8Mhrs
3 year warranty

2W - 3W
Output voltages 100VDC to 7kVDC (3W), & 8kVDC to 12kVDC (2W)
Isolated output voltage proportional to input voltage
General purpose, cost effective
Low turn on voltage: <0.7VDC
Positive or negative, reversible polarity
Input voltage 0 to 12VDC, or 0 to 15VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
MTBF>2Mhrs
3 year warranty

1.5W
Output voltages up to 6kVDC
Positive or negative outputs
Isolated output voltage proportional to input voltage
Input voltage 5V, 12V & 24VDC
Low turn on voltage: <0.7VDC
Very low I/O leakage current
Low noise, quasi-sinewave resonant oscillator
Ultra-miniature, low profile
MTBF>1.8Mhrs
3 year warranty

2W
0 to ±2kV bipolar output
4 quadrant operation with active load
Constant voltage control and current limitation with automatic transfer and control mode dispay with LED’s
Single phase AC input
Continuous operation at full rated power
Digital, LAN and USB interface option
Analog programming/interface option
Manual voltage control via 10 turn potentiometer
Digital display for current and voltage
Set-point display via a button
Set-point adjustment possible with disabled output
Push-button switch for output voltage
CE marked, EN61010-1 safety compliant
Short circuit & arc protection
2 year warranty

4W - 20W
Electrostatic high voltage source
Output voltages up to 15kVDC
Single & dual output models
2U ½ 19" rack mount (≥5kVDC models)
2U 19" rack mount (15kVDC model)
Output current range: 100μA – 10mA
Auto-polarity reverse
Auto-discharge
Short & open circuit protection for enhanced reliability
Input voltage 24VDC
Built-in EMI filtering available
Output to input isolation: > 500MΩ
Analog / RS232 / DeviceNet (option)
3 year warranty

3.5W
0 to ±3.5kV bipolar output
4 quadrant operation with active load
Constant voltage control and current limitation with automatic transfer and control mode dispay with LED’s
Single phase AC input
Continuous operation at full rated power
Digital, LAN and USB interface option
Analog programming/interface option
Manual voltage control via 10 turn potentiometer
Digital display for current and voltage
Set-point display via a button
Set-point adjustment possible with disabled output
Push-button switch for output voltage
CE marked, EN61010-1 safety compliant
Short circuit & arc protection
2 year warranty

5W
Output voltages up to 6kVDC
0 to 100% programmable output voltage
Load and line regulation <0.01%
Low ripple <0.01%
Voltage & current monitor output
+24VDC input (22 to 30VDC)
On-board +5VDC reference
Short circuit, arc, and overload protection
64.8 x 33.0 x 15.2 mm package
UL62368 and UL61010 approvals
Operating temperature: -40°C to +70°C
3 year warranty

7W
Output voltages 0-125VDC to 0-35kVDC
Single phase AC input
Continuous operation at full rated power
Screwdriver operated multi-turn potentiometer for voltage setting
Screwdriver operated multi-turn potentiometer for current limit setting
Control mode display with LED’s
Constant voltage (CV) or constant current (CC) operation with automatic transfer
Analog programming/interface with set point inputs
HV On/Off
Front panel output sockets for voltage & current monitors
Short circuit & arc protection
2 year warranty
| Product image | Series | Features | Actions |
|---|---|---|---|
![]() | HVT0W |
| |
![]() | G0.44W - 1.5W |
| |
![]() | Q0.5W |
| |
![]() | AG1W |
| |
![]() | GP1W |
| |
![]() | MS Source1W |
| |
![]() | HCB1.41.4W |
| |
![]() | MS Detector1W |
| |
![]() | CB1W |
| |
![]() | CA-T1W |
| |
![]() | CA1W |
| |
![]() | C1W |
| |
![]() | A1W |
| |
![]() | E2W - 3W |
| |
![]() | AH1.5W |
| |
![]() | HCB22W |
| |
![]() | ESC4W - 20W |
| |
![]() | HCB3.53.5W |
| |
![]() | HRC055W |
| |
![]() | HCE77W |
|
