HRL30 Series

High Voltage DC-DC

HRL30 Series

HRL30 series of miniature high voltage DC-DC converters offer output up to 6kVDC at 30W

The HRL30 series, is a 30W regulated high voltage DC-DC converter product line, taking us to the next level of output power in our miniature high voltage product offering.

HRL30 is the first DC-HVDC product in our product line that provides both voltage and current mode controls. This product is using an updated design topology, making it easier to deliver accurate high voltage with higher efficiency.

Some of the prominent product features are smaller size, constant voltage and constant current control with superior thermal performance. Typical applications: Mass spectrometry; Electrostatic chuck; Detectors (Photomultiplier tubes); E-beam/ion beam; Electrophoresis, Scanning Electron Microscopes (SEMs), Capacitor charging.

datasheet Contact us

Features

  • High voltage DC-DC converters
  • +24VDC input [22 to 30V]
  • Output voltage & current regulated
  • 0 to 100% programmable output & current
  • Voltage & current monitor outputs
  • Short circuit, arc, and overload protections
  • On-board +5V reference
  • Efficiency >80%
  • Low Ripple <0.05%
  • Premier thermal performance
  • -40°C to +70°C operating temperature
  • 3 year warranty
Model Name Power Output Voltage Input Voltage Output Regulation Datasheet Stock Check RFQ
HRL30 HRL3024S200N 30 W 0 to 200 V 22 to 30 VDC Regulated
HRL30 HRL3024S200P 30 W 0 to 200 V 22 to 30 VDC Regulated
HRL30 HRL3024S350N 30 W 0 to 350 V 22 to 30 VDC Regulated
HRL30 HRL3024S350P 30 W 0 to 350 V 22 to 30 VDC Regulated
HRL30 HRL3024S600N 30 W 0 to 600 V 22 to 30 VDC Regulated
HRL30 HRL3024S600P 30 W 0 to 600 V 22 to 30 VDC Regulated
HRL30 HRL3024S1K0N 30 W 0 to 1 kV 22 to 30 VDC Regulated
HRL30 HRL3024S1K0P 30 W 0 to 1 kV 22 to 30 VDC Regulated
HRL30 HRL3024S1K5N 30 W 0 to 1.5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S1K5P 30 W 0 to 1.5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S2K0N 30 W 0 to 2 kV 22 to 30 VDC Regulated
HRL30 HRL3024S2K0P 30 W 0 to 2 kV 22 to 30 VDC Regulated
HRL30 HRL3024S2K5N 30 W 0 to 2.5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S2K5P 30 W 0 to 2.5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S3K0N 30 W 0 to 3 kV 22 to 30 VDC Regulated
HRL30 HRL3024S3K0P 30 W 0 to 3 kV 22 to 30 VDC Regulated
HRL30 HRL3024S4K0N 30 W 0 to 4 kV 22 to 30 VDC Regulated
HRL30 HRL3024S4K0P 30 W 0 to 4 kV 22 to 30 VDC Regulated
HRL30 HRL3024S5K0N 30 W 0 to 5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S5K0P 30 W 0 to 5 kV 22 to 30 VDC Regulated
HRL30 HRL3024S6K0N 30 W 0 to 6 kV 22 to 30 VDC Regulated
HRL30 HRL3024S6K0P 30 W 0 to 6 kV 22 to 30 VDC Regulated

Specifications


Dimensions

HRL30: 3.0 x 1.5 x 0.75” (76.2 x 38.1 x 19.05 mm)

Input Voltage

22 to 30VDC (24V nominal)

Operating Temperature

-40 to +70°C

Isolation

Input to Output: N/A – Input ground is internally connected to output ground

Worldwide Safety Approvals

IEC60950, IEC62368

European Safety Approvals

EN60950, EN62368

US Safety Approvals

UL60950, UL62368

Other Safety Approvals

CE Directive, RoHs and LVD, RoHS 2 and 3 Directive (2011/65/EU), CSA 60950, CSA 62368
