DC-DC Converters
LDU08 Series
- DC Input LED Driver
- Constant Current Output
- LED Drive Current up to 1000 mA
- LED Strings from 2 V to 57 V
- PWM & Analog Dimming Control
- Open or Short Circuit LED Protection
- 3 Year Warranty
| Model Name | Power | Input Voltage | Output Voltage | Output Current | Datasheet | Stock Check | RFQ | |
|---|---|---|---|---|---|---|---|---|
|
|
LDU0830S300 | 8 W | 7 to 30 VDC | 28V | 0.3A |
|
|
|
|
|
LDU0830S350 | 8 W | 7 to 30 VDC | 28V | 0.35A |
|
|
|
|
|
LDU0830S350-W | 8 W | 7 to 30 VDC | 28V | 0.35A |
|
|
|
|
|
LDU0830S350-WD | 8 W | 7 to 30 VDC | 28V | 0.35A |
|
|
|
Specifications
Dimensions
0.80 x 0.40 x 0.40 in (20.3 x 10.2 x 10.2 mm)
Input Voltage
7-30 VDC LDU48: 7-60 VDC
Efficiency
95% typical
Operating Temperature
-40 °C to +85 °C
EMC
EN55022 class B conducted & radiated with external components - see datasheet
